Mogs 2mm MLS72 TB | Lift&Slide

#Ottostumm

Mogs 2mm MLS72 TB | Lift&Slide

The Lift&Slide system MLS72 TB is a system for sliding openings of extraordinary weights and dimensions.
The system consists of solid steel tubular profiles, made of 2 mm thick sheet and shaped to form gasket grooves and a reinforced housing for the hardware. A slender frame (only 18 mm) with maximum resistance and the high thermal-acoustic performance of the thermal break technology in PA 6.6 polyamide. The profile depth of 72 mm allows the housing of large insulating glass panes, for door weighing up to 400 kg each leaf.

MLS72 TB is available in galvanized steel which can be finished in any colour, Cor-Ten steel and stainless steel AISI 316L.

SYSTEM FEATURES

continuously laser welded profile, thickness 2 mm
aesthetic cover cap with insulating material
insulator
glassfibre reinforced PA 6.6 polyamide
insulated front strike
rebate gaskets
gasket groove
thermal break profiles, available in galvanized steel, Cor-ten steel and stainless steel AISI 316L 2B
thermally insulated stainless steel threshold
compatible with insulating glazing, including security glass
tubolar snap on or “L” shaped, angular glazing beads
choice of handles with different design
up to 400 kg
perimeter wall recessed frame
